2015-2022 GM 8L45/8L90 Heavy-Duty Cast Aluminum Deep Transmission Pan

Name: 2015-2022 GM 8L45/8L90 Heavy-Duty Cast Aluminum Deep Transmission Pan
Brand: Pacific Performance Engineering
SKU: 128051700
Price: 536.0 AUD
Availability: InStock

$536.00 In Stock Temporarily Out of Stock

PART NUMBER: 128051700 GTIN: 840171222678

Features

High-grade A356.0-T6 heat-treated cast aluminum alloy
Increases fluid capacity by 3.8 quarts
3/4-inch external fins improve heat dissipation, lower transmission fluid temperature, and increase strength
7/8-inch internal baffles further improve heat dissipation, reduce fluid sloshing
CNC machined grooves at bottom increase effective surface area which accelerate heat radiation
High-power Neodymium-magnet-equipped billet stainless steel plugs with Viton O-rings
Tapped and plugged 1/8-inch NPT port for optional temperature sensor
Gussets provide extra support to the flange and increase robustness
Compatible with OEM gasket

FREE SHIPPING FOR ORDERS OVER $100

LIFETIME LIMITED WARRANTY

30-DAY RETURNS

Description
Compatible Vehicles
Downloads
Reviews

Heavy-Duty Cast Aluminum Deep Transmission Pan for 2015-2022 GM w/ 8L45/8L90 Transmission

PPE’s Heavy-Duty DEEP 8L90 Transmission Pan holds an extra 3.8 quarts of fluid and is cast from high-quality A356.0-T6 aluminum alloy for strength and optimum heat dissipation.

An integrated fluid level check tube, sealed by PPE half-inch stainless steel Neodymium magnet-equipped plug. The drain port features a one-inch, high-power Neodymium magnet-equipped stainless steel drain plug. Both plugs catch and hold harmful ferrous particles and keep them out of the transmission internals.

OEM Part Number for Reference: GM 24278774

Note: This pan does not fit 2019 and newer Silverado/Sierra 1500 with 8L90 Transmission

Make sure your vehicle is equipped with the 8-speed transmission even if the Year/Make/Model of your vehicle falls in the range of the application list.
