More capacity. Better cooling. Real protection.
2018-2025 Jeep Wrangler 2.0L Heavy-Duty Cast Aluminum Engine Oil Pan
Whether your stock-stamped steel oil pan has been damaged, or you want a simple bolt-on upgrade with better performance, the PPE Cast Aluminum Engine Oil Pan is your best choice for increased strength and lower oil temps.
Thick cast aluminum is far superior to the stock-stamped steel for cooling engine oil. PPE has engineered deep exterior fins that follow underside airflow and increase surface area to radiate heat better than stock. Cast gussets provide strength and rigidity to the housing. We’ve even upgraded the drain plug. Our exclusive PPE High-Power Neodymium Magnet Equipped, Billet, Hardened Stainless Steel Drain Plug is included. The high-power Neodymium magnet pulls ferrous metals out of the oil before they do damage. The factory plug has no magnet and provides no protection.
Upgrade performance looks, and quality with this easy install.
2018-2025 Jeep Wrangler 2.0L Heavy-Duty Cast Aluminum Engine Oil Pan
Features
- Premium A356.0-T6 heat-treated cast aluminum alloy – a high-strength, thermally conductive material
- Precision-cast using permanent steel molds for a smooth, consistent finish and high dimensional accuracy
- Increases oil capacity by a half quart for higher thermal capacity
- Half-inch external fins improve heat dissipation, lower transmission fluid temperature, and increase impact resistance
- Cast-in gussets for additional upper oil pan flange support and increased rigidity
- Precision machined sealant grooves guide the application of RTV-style sealant for a consistent bead and a reliable seal
- Stainless steel drain plug with built-in high temperature rated neodymium magnet
- Equipped with a 1/8-inch NPT port with pre-installed NPT plug
Applications & Product Links:
2018-2026 Jeep Wrangler 2.0L Heavy-Duty Cast Aluminum Engine Oil Pan
2018-2025 Jeep Wrangler/Gladiator 3.6L Heavy-Duty Cast Aluminum Engine Oil Pan
2011-2023 Dodge Charger/Challenger/300, 2012-2018 Jeep Wrangler 3.6L Heavy-Duty Cast Aluminum Engine Oil Pan
2013-2018 RAM 1500, 2011-2026 Dodge Durango, 2011-2022 Jeep Grand Cherokee 3.6L Heavy-Duty Cast Aluminum Engine Oil Pan
2007-2011 Jeep Wrangler 3.8L Heavy-Duty Cast Aluminum Engine Oil Pan
2018-2026 Jeep JL/JT 2.0L/3.0L/6.4L, 850RE/8HP75 Heavy-Duty Cast Aluminum Transmission Pan - Deep
FEATURES
- Premium A356.0-T6 heat-treated cast aluminum alloy – a high-strength, thermally conductive material
- Precision-cast using permanent steel molds for a smooth, consistent finish and high dimensional accuracy
- Increases fluid capacity by 2.2 quarts for higher thermal capacity
- Tall 3/4-inch external fins improve heat dissipation, lower transmission fluid temperature, and increase impact resistance
- Half-inch internal baffles enhance heat absorption and minimize fluid sloshing
- External fins and internal baffles work together to form an ultra-strong Cross-Bracing structure
- 304 Stainless steel drain plug with built-in high temperature rated neodymium magnet and Viton O-ring
- Equipped with a 1/8-inch NPT port with pre-installed NPT plug
- Integrated filter supports ensure proper filter placement
- Compatible with OEM gasket
- New transmission filter included (228058600)
Applications & Product Links:
2018-2026 Jeep JL/JT 2.0L/3.0L/6.4L, 850RE/8HP75 Heavy-Duty Cast Aluminum Transmission Pan - Deep
2013-2025 RAM/Dodge/Jeep/BMW/Toyota Supra ZF 8-Speed Heavy-Duty Cast Aluminum Transmission Pan
Features
- Premium A356.0-T6 heat-treated cast aluminum alloy – a high-strength, thermally conductive material
- Precision-cast using permanent steel molds for a smooth, consistent finish and high dimensional accuracy
- Increases fluid capacity by 1 quart for higher thermal capacity
- Tall 3/4-inch external fins improve heat dissipation, lower transmission fluid temperature, and increase impact resistance
- Half-inch internal baffles enhance heat absorption and minimize fluid sloshing
- External fins and internal baffles work together to form an ultra-strong Cross-Bracing structure
- 304 Stainless steel drain plug with built-in high temperature rated neodymium magnet and Viton O-ring
- Equipped with a 1/8-inch NPT port with pre-installed NPT plug
- Integrated filter supports ensure proper filter placement
- Compatible with OEM gasket and steel collars
- New transmission filter included (228058700)
Applications & Product Links:
2013-2025 RAM/Dodge/Jeep/BMW/Toyota Supra ZF 8-Speed Heavy-Duty Cast Aluminum Transmission Pan
2018-2026 Jeep JL/JT 2.0L/3.0L/6.4L, 850RE/8HP75 Heavy-Duty Cast Aluminum Transmission Pan
2005-2019 Jeep/Dodge/Chrysler WA580, W5A580, NAG1 Heavy-Duty Cast Aluminum Transmission Pan
FEATURES
- Premium A356.0-T6 heat-treated cast aluminum alloy – a high-strength, thermally conductive material
- Precision-cast using permanent steel molds for a smooth, consistent finish and high dimensional accuracy
- Increases fluid capacity by 3/4 quart for higher thermal capacity
- Tall 3/4-inch external fins improve heat dissipation, lower transmission fluid temperature, and increase impact resistance
- Half-inch internal baffles enhance heat absorption and minimize fluid sloshing
- External fins and internal baffles work together to form an ultra-strong Cross-Bracing structure
- Cast-in gussets for additional transmission housing flange support and increased rigidity
- 304 Stainless steel drain plug with built-in high temperature rated neodymium magnet and Viton O-ring
- Equipped with a 1/8-inch NPT port with pre-installed NPT plug
- Compatible with OEM filter
Applications & Product Links:
2005-2019 Jeep/Dodge/Chrysler WA580, W5A580, NAG1 Heavy-Duty Cast Aluminum Transmission Pan
2011-2023 Dodge Charger/Challenger/300, 2012-2018 Jeep Wrangler 3.6L Heavy-Duty Cast Aluminum Engine Oil Pan
2011-2018 RAM 1500/2500/3500, 2010-2013 Jeep Grand Cherokee 65RFE/66RFE Heavy-Duty Cast Aluminum Transmission Pan
Features
- Premium A356.0-T6 heat-treated cast aluminum alloy – a high-strength, thermally conductive material
- Precision-cast using permanent steel molds for a smooth, consistent finish and high dimensional accuracy
- Increases fluid capacity by 1.8 quarts for higher thermal capacity
- Tall 3/4-inch external fins improve heat dissipation and increase impact resistance
- Deep 3/4-inch internal baffles enhance heat absorption and minimize fluid sloshing
- External fins and internal baffles work together to form an ultra-strong Cross-Bracing structured
- Cast-in gussets for additional transmission housing flange support and increased rigidity304 Stainless steel drain plug with built-in, high-temperature-rated neodymium magnet and Viton O-ring
- New spin-on filter included SKU 228052150
Applications & Product Links:
MicroPure® Engine Oil Filter - Replaces AC Delco PF48 PF63, Motorcraft FL500S, Mopar MO339
FEATURES
- MicroPure® filtration with a 10-micron nominal rating
- Durability that will last the lifetime of the vehicle
- OEM fitment
- Stainless steel construction with high-quality rubber seal
- Durability that will last the lifetime of the vehicle
- OEM fitment
- Stainless steel construction with high-quality rubber seal
- Durability that will last the lifetime of the vehicle
- OEM fitment
- OEM fitment
Applications & Product Links:
MicroPure® Engine Oil Filter - Replaces AC Delco PF48 PF63, Motorcraft FL500S, Mopar MO339
MicroPure XR® Engine Oil Filter - Replaces AC Delco PF26, Motorcraft FL-820S, Mopar MO-899
Hard Anodized Billet Aluminum Oil Filter Socket - 76mm 14F
Features
- Hard anodized 6061-T6 Aluminum
- Works with a 3/8-inch square drive or a 1-inch socket
- 76mm, 14-Flute
Applications & Product Links:
